KNOWLEDGE BASE
| Basic |
|
|
|
Standard Wheel Deck | Front Wheel Mount | Side Mount | Asetek Mount | |
Asetek SimSports | La Prima 12 Nm | La Prima 12 Nm | ||
Accuforce | V1, (Pro) V2 | |||
Fanatec |
CSL, CSW (2.5) | CSLDD / Pro / GT ClubSport DD DD1, DD2 | ||
Logitec |
G25, G27, G920, G923 | |||
Moza | R5, R9, R12, R16, R21 | |||
Simagic |
Alpha | Alpha | Alpha U | |
Simucube |
Simucube Sport | |||
Thrustmaster |
T150, T300, T500RS, TX,
TMX | |||
VRS | VRS Direct Force Pro |
We deliver the following bolts to connect wheel bases with each wheel mounting option:
Mounting kit | Standard Wheel Deck
| Front Wheel Mount
| Side Mount
| Asetek Mount:
|
| Basic |
|
|
Asetek SimSports | Forte | Forte | Forte |
Fanatec | CSL Elite (LC) (V2) | CSL Elite (LC) (V2) | CSL Elite (LC) (V2) Clubsport V3 |
Heusinkveld | Sprint | Sprint | |
Logitec |
G25, G27, G920, G923 included pedals | G25, G27, G920, G923 included pedals | G25, G27, G920, G923 included pedals |
Moza |
SR-P (Lite) | SR-P (Lite) | SR-P (Lite) |
Simagic |
P1000 | P1000 | P1000 P1000 Inverted P2000 |
Sim-Lab | XP1 | XP1 | |
Simucube | Throttle |
The pedals are only compatible when mounted on the Simucube baseplate. | The baseplate from Simucube is compatible with our Seat Slider. So you'll only need those 2 items, and not our Pedal Slider. |
Thrustmaster | F1, T3Pa, T3PM, T-LCM | F1, T3Pa, T3PM, T-LCM | F1, T3Pa, T3PM, T-LCM |
VRS | Pro Pedals |
| Pro Pedals |
We deliver the following bolts/nuts with our products:
Mounting kit | One, One Basic, Ace and Formula
| Rookie
| Pedal Slider Complete
|
If you need additional bolts, check out our DIY section, or more specifically our Heusinkveld Mounting Set which can be used to mount all sorts of stand alone pedals.
PEDAL BRACKETS
Our pedal deck consists primarily of two brackets that are ment for mounting three aluminum extrusion profiles. One 8040 and two 4040's. This gives you an almost unlimited amount of pedal compatibility. If you've got pedals that are not featured in the table above, than see this sketch if they will fit or not. The 110mm and 153mm slotted holes can be used to slide the extrusion profiles.
PEDAL SLIDER BASEPLATE
The baseplate of the Pedal Slider has the following dimensions (in millimeters):
All our sim rigs and most of our accessories use aluminum extrusion profiles. The dimensions can be found here:
Aluminum Profile Systeem: | ITEM, ISB, ISP, I-Type |
Profile T-slot: | 8 mm (-0 / + 0,3 mm) |
Profile series: | 40 mm |
Profile core: | 6,8 mm |
Thread size (optional): | M8 x 15 mm |
BLACK ANNODIZING
The profiles are annodized with a black finish. Anodizing increases resistance to corrosion and wear, and gives the products a better look and feel. The surface of the profiles can be prone to scratching, but most scratches can later be removed by using an abrasive sponge.
PROFILE DEPTH
The depth of each profile slot is 12 mm. This is an important size when choosing which size of bolt to use, since a bolt that is too long will bite into the profile and cannot be tightend.
Maximum bolt lenght (mm) = 12 + thickness of the part you want to mount.
If you want to use our logo's on your custom made sim racing livery, we are more than happy to supply you with one!
Here you can find high resolution PNG images or our logo:
TREQ BLUE
When we use a solid blue color for text, images, etc, we use the following:
|
- HEX: #176ab3
- RGB: 23, 106, 179
- CMYK: 87, 54, 0, 0
WALLPAPERS
8K Wallpapers - 7860 x 4320 pixels. Click here to download the images (50 mb).
